Boiler Feed Pump Selection Data

  • Very similar to the Condensate Pumps

  • Voltage- Needs to be exact example

  • 230-3-60 not 230/460-3-60

  • Simplex or Duplex

  • Load - Typical units include EDR, BTU, Pound /HR

  • Back Pressure -  Always has a Static Pressure to over come.  Need Static (Max Boiler Pressure) + lift + distance and size  pipe.

Mandatory Equipment

  • Tank

  • Pump

  • Float Switch & Solenoid Make Up Valve

  • The BWLC located on the Boiler Starts and Stops the Pumps

  • Requires Starters for both single and three phase

  • Alternation is available for  Duplex Units.
