Design Features
RECEIVER TANKS
304 stainless steel construction for lifetime service
Available in 10, 24, 44, 70 and 100 gallon sizes
All tanks have studs on the top to allow for the mounting of a customer supplied control panel Vented tanks are designed for gravity return systems
20 year tank warranty
MOTORS
TEFC three phase 3500 RPM NEMA motors are standard. They utilize dual deep groove ball bearings and a stainless steel shaft.
ODP single phase 3500 RPM motors are standard from 1/3 HP thru 2HP. They are rated 115/208-330 Volt 60HZ.
3HP is 230 Volt only. All single phase motors have built-in overload protection
Three phase motors are 208-230/460 Volt 60HZ.
All three phase motors must be installed with a magnetic starter which provides overload protection
PUMPS
Vertical flange-mounted pumps are investment cast 304 stainless steel fitted with mechanical seal rated to 300°F
Each pump utilizes a vented and flushed seal area
The hydraulic design allows for non-overloading performance at the listed ratings
Pumps are fitted with silicone bronze impellers for smooth, quiet operation
All pumps utilize a back pull-out design which allows for servicing without disturbing piping
OPTIONAL FEATURES
Basket Strainers
Y Strainers
Suction isolation valves
X-Proof motor enclosures
Various mechanical seal upgrades
Control Panel
Dial Thermometer with brass well
Gauge Glass
Pressure Gauge with shut-off valves
